Projection System

• DLP™

Light Source

• 220 W OSRAM

Light Source Life

• 5000 hours (Standard), 6000 hours (ECO)

Native Resolution

• 1280 x 800

Maximum Resolution

• 1920 x 1200

Brightness

• 4000 ANSI Lumens (Standard), 2880 lm (ECO)

Aspect Ratio

• 16:10 (Native), 4:3 (Supported), 16:9 (Supported)

Contrast Ratio

• 25,000:1

Image Size

• 36" (91.4 cm) ~ 7.62 m (300")

Throw Ratio

• 0.52 (2209.8 mm@980 mm)

Zoom Ratio

• 1x

Digital Zoom

• 2x

Lens

• F = f/2.80, f = 7.51 mm, Manual Focus

Projection Mode

• Front, Rear, Ceiling, Rear Ceiling

Display Color

• 1.07 Billion Colors (30-bit)
• 1.07 Billion Colors (30-bit)

Vertical Sync Rate

• 24 ~ 120 Hz

Horizontal Sync Rate

• 15 to 100 kHz

VGA In

• x1, D-sub

VGA Out

• x1, D-sub

Video

• x1, RCA

Audio In

• x1, 3.5mm mini jack

Audio Out

• x1, 3.5mm mini jack

S/PDIF

Speaker

• x1, 16 W Speaker
• x1, 16 W Speaker

Power Consumption

• 270Watts (Standard), 210Watts (ECO)

Installation

• Ceiling Mountable

[Dimensions (W x D x H)

• 313 mm (12.32") x 255.25 mm (10.05") x 113.70 mm (4.48")
• 313 mm (12.32") x 255.25 mm (10.05") x 113.70 mm (4.48")

Weight (Approximate)

• 3.1 kg (6.8 lb)
